reComputer J3010 – With NVIDIA Jetson Orin Nano 4GB module
reComputer J3010 equips NVIDIA Jetson Orin Nano 4GB module delivering up to 20TOPS AI computing performance. Compact hand-sized enclosure with abundant IOs, pre-installed JetPack5.1 & 128GB NVMe SSD, ideal for edge AI vision deployment.
Description
Core Specification
- Core Module: NVIDIA Jetson Orin Nano 4GB
- GPU: 512-core Ampere GPU with 16 Tensor Cores, max 625MHz
- CPU: 6-core Cortex-A78AE 64-bit, peak 1.5GHz
- RAM: 4GB LPDDR5 @34GB/s bandwidth
- Enclosure Size: 130×120×58.5mm, working temp: -10℃~60℃
- Input Power: 9~19V DC, matched 12V/5A power adapter
Rich Interfaces
HDMI2.1, 1×GbE LAN, 4×USB3.2, 2×CSI, M.2 Key M/M.2 Key E, CAN bus, 40Pin GPIO, RTC socket and PWM fan header, supports WiFi/BT via M.2 E key. Powerful multi-channel video codec: single 4K@60fps H.265 decode and multi-stream 1080P decoding.
Product Highlights
- Up to 20TOPS AI inference performance matching Xavier NX level, low power & low latency for on-site industrial AI processing.
- Complete preconfigured system: JetPack5.1 OS + 128GB NVMe SSD + preassembled heatsink, WiFi-BT module with dual antennas out of box, greatly shortening project development cycle.
- Flexible installation: desktop placement or wall-mounted installation to adapt various on-site deployment environments.
- Certified with CE/FCC/RoHS/UKCA for industrial and commercial market access.
Application Scenarios
Machine vision, intelligent monitoring, industrial edge computing, automated inspection and embedded AI development projects.
